Mechanical Signalling

Duration:

5 Days

Location:

Derby / Your Premises

Certification:

Certificate of Attendance

Underpinning Knowledge in the principles of mechanical Signalling
Practical experience in the cutting of mechanical locks (FPL) and the jointing of Signal wires
Maintenance and installation techniques and standards

Who Should Attend This Course?

This course is intended for signal engineers who will become involved in the maintenance or installation of mechanical signalling and will provide them with a good level of underpinning knowledge.

Course Content and Learning Outcomes

On successful completion of this course, the delegate will be able to describe the function of the following:

‍

Signals:

‍

Signal Structures
Signal Fittings
Slotting
Signal Wire Runs
Signal Box Wire Connections
Jointing and terminating Signal Wire
Signal Arm Gauge
Signal Arm Repeating
Final Checks on Signal Operation

‍

Points:

‍

Point Types and Identification
Point Operation
Rodding Runs
Compensation
Facing Point Lock Plunger Operation
Adjustment of Points

‍

Detection:

‍

Detection Theory
Detection Equipment
Cutting of Detector Notches
Adjustment and Testing of Detectors

Download Full Syllabus (PDF)

Available Dates

Enquire About This Course

No Available Dates

Entry
Requirements

A well prepared delegate is expected to have attended some basic training (BS1/BS2/ Introduction to Signalling) or have equivalent experience. The delegates should have some experience with basic hand tools (i.e. Hacksaw, file etc.) although some instructions will be given on the course.

Check Your Eligibility
